Seismic Elastomeric Corridor Wall & Ceiling System - Surface Application (LCS/LCSw)

Part Number:
EJN-LCS/LCSw
Out of Stock
Learn More

Description

The Seismic Elastomeric Corridor Wall and Ceiling System seamlessly integrates with wall, ceiling and corner applications. The V seal design allows for maximum thermal and seismic movement.

Features

  • Horizontal and Vertical Thermal Movement
  • Seismic Movement with Lateral Shear
  • Surface Mount
  • Coordinating Corners
  • 4 Complementary Seal Colors

Specifications

Model LCS/LCSw
Material 6063-T6 Aluminum, Meets ASTM B209
Finish Mill
Movement Thermal: Horizontal and Vertical
Seismic: Lateral Shear
Mounting Surface
Joint Size 2 to 6 inches
Length Aluminum 10 Linear Feet, Seals Longest Practical Continuous Length
Application Interior
Installation Wall or Ceiling
Options Moisture barrier, Fire barrier and Additional Materials, Sizes and Finishes upon request
Warranty 1 year

Colors Beige
Beige
White
White
Gray
Gray
Black
Black

Order Guide

Use the table below to guide specification of available options. The part numbers are indicated in BOLD ORANGE text.

PART NUMBER APPLICATION JOINT SIZE
at mean T°F
EXPOSED
SIGHT LINE
TOTAL
MOVEMENT
EJN-LCS-200 Wall/Ceiling to Wall/Ceiling 2" (51mm) 4.87" (124mm) 2" (51mm)
EJN-LCS-300 Wall/Ceiling to Wall/Ceiling 3" (76mm) 5.87" (149mm) 3" (76mm)
EJN-LCS-400 Wall/Ceiling to Wall/Ceiling 4" (102mm) 6.87" (175mm) 4" (102mm)
EJN-LCS-500 Wall/Ceiling to Wall/Ceiling 5" (127mm) 7.87" (200mm) 5" (127mm)
EJN-LCS-600 Wall/Ceiling to Wall/Ceiling 6" (152mm) 8.87" (226mm) 6" (152mm)
EJN-LCS-200w Wall/Ceiling to Corner 2" (51mm) 3.5" (87mm) 2" (51mm)
EJN-LCS-300w Wall/Ceiling to Corner 3" (76mm) 4.5" (113mm) 3" (76mm)
EJN-LCS-400w Wall/Ceiling to Corner 4" (102mm) 5.5" (138mm) 4" (102mm)
EJN-LCS-500w Wall/Ceiling to Corner 5" (127mm) 6.5" (164mm) 5" (127mm)
EJN-LCS-600w Wall/Ceiling to Corner 6" (152mm) 7.5" (189mm) 6" (152mm)

WARRANTY

NYSTROM warrants all Expansion Joint Systems to be free from manufacturing defects in materials, factory finishes, and workmanship for a period of one (1) year from the date of shipment.

Should a product fail to function in normal use within this period, Nystrom shall furnish a replacement or new part at Nystrom's discretion. Failure to use product in methods consistent with Nystrom product manuals shall relieve Nystrom of any liability. Our liability under this warranty excludes installation or removal costs involved in the product replacement and excludes any responsibility for incidental or consequential damage of any nature.


For information on a warranty claim, please visit our Warranty Support section or call 800 547-2635.

Warranty Support

Videos

Coming soon.
Coming soon.
Description Model Shop Drawing CAD Revit/BIM Data Sheet 3-Part Specs LEED Installation Warranty
Wall/Ceiling to Wall/Ceiling EJN-LCS-200 PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Wall/Ceiling EJN-LCS-300 PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Wall/Ceiling EJN-LCS-400 PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Wall/Ceiling EJN-LCS-500 PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Wall/Ceiling EJN-LCS-600 PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Corner EJN-LCS-200w PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Corner EJN-LCS-300w PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Corner EJN-LCS-400w PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Corner EJN-LCS-500w PDF DWG LINK PDF WORD PDF PDF PDF
Wall/Ceiling to Corner EJN-LCS-600w PDF DWG LINK PDF WORD PDF PDF PDF

Specifications

Application:
Interior Wall & Ceiling
Material Type:
Elastomeric Seal
Movement Type:
Seismic, Thermal
