Seismic Pre-Compressed Horizontal Foam System Recessed Application (HES)

Part Number:
EJN-HES
Out of Stock
Learn More

Description

The Nystrom Seismic Pre-Compressed Horizontal Foam System is a high-movement silicone bellow system used in deck or roof perimeters. It is a watertight system that can be used under a cover plate in pedestrian or light vehicular traffic areas.

Features

  • Multi-Functional
  • Color Coordinating
  • Horizontal Installation
  • Non-Invasive Anchoring
  • Wax Free

Specifications

Model EJN-HES
Material Foam with silicone bellow
Joint Sizes ½ inch to 10 inches
Sizes available in ¼-inch increments from 1 inch to 10 inches
Sizes from ½ inch to 1-¼ inches are manufactured with a double silicone face bellow
Larger sizes up to 10 inches are manufactured with multiple bellows
Length 6.56 linear feet (2 meters)
Application Interior or Exterior
Installation Horizontal (Non-Traffic)
Certifications STC52, OITC38
Options Terminations, Transitions, Seal Depths, Dual Sided, Uncoated, and Pick Resistant Sealant
Movement +/-50% (Total 100%)
Warranty 1 year

Colors Adobe Tan
Adobe Tan
Aluminum Stone
Aluminum Stone
Buff
Buff
Anodized Aluminum
Anodized Aluminum
Black
Black
Bronze
Bronze
Champagne
Champagne
Charcoal
Charcoal
Dark Bronze
Dark Bronze
Dusty Rose
Dusty Rose
Gray
Gray
Ivory
Ivory
Light Bronze
Light Bronze
Limestone
Limestone
Precast White
Precast White
Rustic Brick
Rustic Brick
Sandstone
Sandstone
Off White
Off White
White
White

Order Guide

Use the table below to guide specification of available options. The part number components are indicated in BOLD ORANGE text.

MODEL JOINT SIZE
at mean T° F
SEAL DEPTH
EJN-HES-050 ½” (13mm) 2” (51mm)
EJN-HES-063 5/8” (16mm) 2” (51mm)
EJN-HES-075 ¾” (19mm) 2” (51mm)
EJN-HES-100 1” (25mm) 2” (51mm)
EJN-HES-200 2” (51mm) 3” (76mm)
EJN-HES-300 3” (76mm) 3” (76mm)
EJN-HES-400 4” (102mm) 4” (102mm)
EJN-HES-500 5” (127mm) 4” (102mm)
EJN-HES-600 6” (152mm) 6” (152mm)
EJN-HES-700 7” (178mm) 6” (152mm)
EJN-HES-800 8” (203mm) 6” (152mm)
EJN-HES-900 9” (229mm) 8” (203mm)
EJN-HES-1000 10” (254mm) 8” (203mm)

Movement of +/-50% (Total 100%)

Note: Sizes under 1-½” (38mm) are manufactured with a double silicone face bellow. Larger sizes up to 10” (254mm) are manufactured with multiple bellows.

Additional sizes available in ¼” increments from 1” to 10”.

WARRANTY

NYSTROM warrants all Expansion Joint Systems to be free from manufacturing defects in materials, factory finishes, and workmanship for a period of one (1) year from the date of shipment.

Should a product fail to function in normal use within this period, Nystrom shall furnish a replacement or new part at Nystrom’s discretion. Failure to use product in methods consistent with Nystrom product manuals shall relieve Nystrom of any liability. Our liability under this warranty excludes installation or removal costs involved in the product replacement and excludes any responsibility for incidental or consequential damage of any nature.


For information on a warranty claim, please visit our Warranty Support section or call 800 547-2635.

Warranty Support

Videos

Coming soon.
Coming soon.
Description Model Shop Drawing CAD Revit/BIM Data Sheet 3-Part Specs LEED Installation Warranty
Horizontal Deck EJN-HES-050 to EJN-HES-1000 PDF DWG PDF WORD PDF PDF

Specifications

Category:
compression seals
Material:
Silicone Bellow with Foam Sealant
Finish:
Dow 790, Pecora 890
Color:
Adobe Tan, Black, Gray, White, Beige, Limestone, Aluminum Stone, Blue Spruce, Anodized Aluminum, Bronze, Charcoal, Dusty Rose, Natural Stone, Charcoal Gray, Precast, Classic Bronze, Rustic Brick, Sandstone, Hartford Green, Red Rock, Tru White
